Automatic Chainsaw Processor KSA 380 E

For combined sawing and cutting of logs up to 37 cm, the chain saw machine KSA 380 E with a 400 V electric drive is suitable.

Category: SKU: 91915

Additional information

Antrieb

Electric 400 V, 32 A EC plug, Delta-Star switch

Antriebsleistung

7,5 kW P2, 9,5 kW P1

Schnitt Ø

max. 370 mm

Scheitlänge

Adjustable: 200–520 mm

Sägeschwertlänge

15" / 380 mm

Kette

3/8" / 1,5 / 57 TG

Ölvorrat

42 l

Spaltkraft

9 t

Leistung

4–6 cord/h

Länge Förderband

4200 mm

Gürtelbreite Förderband

300 mm

Ladehöhe Förderband

max. 2700 mm

Transportstellung (B x T x H)

2780 x 1100 x 2550 mm

Gewicht

825 kg (1818.8 lb)

Description

  • Noiseless chainsaw operation
  • The oversized pumping capacity (45 l/min = 9.9 gal/min) ensures faster splitting cycles; Moreover, saw-cutting and splitting can be controlled and executed nearly concurrently even with soft, thinner timber
  • Two hydraulic pumps with two separate circuits:
  • 1 pump for log splitter operation (45 l/min = 9.9 gal/min) and 1 pump for chainsaw and infeed belt operation (30 l/min = 6.6 gal/min)
  • Emergency splitter stop by means of a safety hand-lever control
  • Multifunctional control lever designed for controlling four machine functions
  • Hydraulic log conveyor
  • Standard oil cooler to allow for trouble-less, non-stop operation.
